Your components, our precision – contract manufacturing from SCHIESS.

In addition to the manufacture of machine tools, our parts production facility offers productive external production for high-quality workpieces made of cast iron, steel and aluminum for the demanding manufacturing tasks of many branches of industry.

We manufacture high-precision, medium-sized and large parts professionally and on time.

You can find an overview of our machinery and details of the machines in the following machine catalog.

Contact for contract manufacturing



Mr. Liebich

Head of Production
+49 3473 968-160
m.liebich@schiess.de



Mr. Richter

Deputy Production
+49 3473 968-161
s.richter@schiess.de















Bottlenecks in your own production?

Talk to us!

Especially for large and complex parts. And of course also for all other machining operations – turning, milling, grinding…

In addition to the possibilities of mechanical processing, we offer the option of horizontal balancing of components up to 3,000 mm long with a maximum weight of 700 kg.

Contract measurement

Among other things, we have a ZEISS coordinate measuring machine with a working area of 5,000mm x 2,000mm x 2,000mm (LxWxH) to check the production tasks.

The Calypso and Gear Pro measuring software can be used to measure and evaluate all control geometries and spur gear teeth. Renishaw lasers are used for measurements and for setting positioning accuracies on linear and rotary axes. Tilting angle measurements up to 80 m are also possible to determine straightness.

Our expertise is also available to you here as a service.

Quality assurance

SCHIESS bears the seal of certified quality management according to DIN EN ISO 9001:2015.

Our measuring machines are subject to constant monitoring by Zeiss. All QA employees test with the greatest possible care and continuous self- and cross-checking.

All employees working on these machines are qualified in accordance with AUKOM 2. Regular training courses, e.g. on shape and position, guarantee continuous further development.

Quality assurance contact



Mr. Gutmann

+49 3473 968-321
k.gutmann@schiess.de



Mr. Umlauf

+49 3473 968-198
d.umlauf@schiess.de















Measurement technology

ZEISS 3D coordinate measuring machine MMZ-G with rotary table for gear measurements : measuring volume 5000x2000x2800. The machine is equipped with the Zeiss Calypso and Gear Pro Involute measuring software. This enables all standard geometries and cylindrical gears to be measured and evaluated.

3D laser tracker from Leica, measuring radius with reflector 90 m, with T-Probe 15 m. The measuring device is mobile and can be used anywhere. It can be used to measure very large components on the spot; the ZEISS Calypso measuring software is also used here.

Renishaw XL 80 laser interferometer: Measuring range 80 m.

Renishaw XR 20 rotation angle measuring device: Unlimited rotation angle (for rotary axes).

The Renishaw laser measurement system is used for checking and compensating the positioning accuracy of linear and rotary axes on machine tools. In addition, straightness measurements, e.g. of guideways on machine beds, can be carried out up to a length of 80 m.
